Stainless steel flat fan nozzles, mostly means common standard fan nozzles. Since its material is stainless steel, it has excellent corrosive resistance. As flat nozzles, it can produce flat fan shape and uniform spraying drop.
 Stainless Steel Vee jet Flat Fan Spray Nozzles |  Stainless Steel Flat Fan Spray Nozzles |
Description
Model | H-VV; H-VVL; H -U; U |
Inlet connection | 1/8''1/4'' BSPT or NPT |
Spray pattern | Flat Fan |
Working pressure | Up to 35 bar (500 psi) |
Flow Rate | 1.0-410L/min |
Spray angle | 110 degree /95 degree /80 degree /73 degree /65 degree /50 degree /40 degree /25 degree /15 degree /0 degree |
Application | Cleaning,Washing,Rinsing,Cooling,Quenching |
Lead time | 1-2 days after payment |
Delivery | DHL,FedEx,UPS,TNT,EMS |
Payment | T/T,Western Union,Paypal,Credit Card,Ali pay,We chat pay |
Parameter
Spray Angle | Flow Code | Orifice Dia | 1 ( us gal) = 3.785 L ; 1 ( uk gal) = 4.546 L |
| ||||||||||
0.3 bar | 1 bar | 2 bar | 3bar | 4bar | 5bar | 6bar | 7bar | 10bar | 20bar | 35bar | 3 bar | |||
0 degree 15 degree | 0.3 bar | 1 bar | 2 bar | 3bar | 4bar | 5bar | 6bar | 7bar | 10bar | 20bar | 35bar | Spray Angle (3bar) | ||
0017 | 0.28 |
|
| 0.05 | 0.06 | 0.07 | 0.08 | 0.09 | 0.1 | 0.12 | 0.17 | 0.23 |
| |
0033 | 0.38 |
|
| 0.11 | 0.13 | 0.15 | 0.17 | 0.18 | 0.2 | 0.24 | 0.34 | 0.44 | 0 degree | |
0050 | 0.46 |
| 0.11 | 0.16 | 0.2 | 0.23 | 0.25 | 0.28 | 0.3 | 0.36 | 0.51 | 0.67 | ||
0067 | 0.53 |
| 0.15 | 0.22 | 0.26 | 0.31 | 0.34 | 0.37 | 0.4 | 0.48 | 0.68 | 0.9 | ||
01 | 0.66 | 0.12 | 0.23 | 0.32 | 0.39 | 0.46 | 0.51 | 0.56 | 0.6 | 0.72 | 1.0 | 1.3 | ||
015 | 0.79 | 0.19 | 0.34 | 0.48 | 0.59 | 0.68 | 0.76 | 0.84 | 0.90 | 1.1 | 1.5 | 2.0 | ||
02 | 0.91 | 0.25 | 0.46 | 0.64 | 0.79 | 0.91 | 1.0 | 1.1 | 1.2 | 1.4 | 2 | 2.7 | ||
03 | 1.1 | 0.37 | 0.68 | 0.97 | 1.2 | 1.4 | 1.5 | 1.7 | 1.8 | 2.2 | 3.1 | 4.0 | ||
04 | 1.3 | 0.5 | 0.91 | 1.3 | 1.6 | 1.8 | 2.0 | 2.2 | 2.4 | 2.9 | 4.1 | 5.4 | ||
05 | 1.4 | 0.62 | 1.1 | 1.6 | 2.0 | 2.3 | 2.5 | 2.8 | 3 | 3.6 | 5.1 | 6.7 | ||
06 | 1.6 | 0.75 | 1.4 | 1.9 | 2.4 | 2.7 | 3.1 | 3.3 | 3.6 | 4.3 | 6.1 | 8.1 | ||
08 | 1.8 | 1.0 | 1.8 | 2.6 | 3.2 | 3.6 | 4.1 | 4.5 | 4.8 | 5.8 | 8.2 | 10.8 | ||
10 | 2.0 | 1.2 | 2.3 | 3.2 | 3.9 | 4.6 | 5.1 | 5.6 | 6.0 | 7.2 | 10.2 | 13.5 | ||
15 | 2.4 | 1.9 | 3.4 | 4.8 | 5.9 | 6.8 | 7.6 | 8.4 | 9.0 | 10.8 | 15.3 | 20 | ||
20 | 2.8 | 2.5 | 4.6 | 6.5 | 7.9 | 9.1 | 10.2 | 11.2 | 12.1 | 14.4 | 20 | 27 | ||
30 | 3.6 | 3.7 | 6.8 | 9.7 | 11.8 | 13.7 | 15.3 | 16.7 | 18.1 | 22 | 31 | 40 | ||
40 | 4.0 | 5.0 | 9.1 | 12.9 | 15.8 | 18.2 | 20.0 | 22 | 24 | 29 | 41 | 54 | ||
50 | 4.4 | 6.2 | 11.4 | 16.1 | 19.7 | 23 | 25 | 28 | 30 | 36 | 51 | 68 | ||
60 | 4.8 | 7.5 | 13.7 | 19.3 | 24 | 27 | 31 | 33 | 36 | 43 | 61 | 81 | ||
70 | 5.2 | 8.7 | 16 | 23 | 28 | 32 | 36 | 39 | 42 | 50 | 70 | 94 | ||
100 | 6.4 | 12.5 | 23 | 32 | 39 | 46 | 51 | 56 | 60.0 | 72 | 102 | 135 | ||
150 | 7.5 | 18.7 | 34 | 48 | 59 | 68 | 76 | 84 | 90.0 | 108 | 153 | 205 | ||
200 | 8.7 | 25 | 46 | 64 | 79 | 91 | 102 | 112 | 121 | 144 | 205 | 270 | ||
Ordering information
HVV | 1/4'' | – | 316SS | 6510 |
↓ | ↓ |
| ↓ | ↓ |
Nozzle Type | Connector Size |
| Material | Angle plus Flow code |
General Application:
1) Cleaning
2) Rinsing
3) Coating
4) Washing
5) Pressure Washing
6) Surface Preparation
Cleaning road
Car wash Machine
Removing stains
Washing
Shanghai XinHou Spraying Purification Equipment Co., Limited is good at producing fan spray nozzle and is the Top manufacturer in China. We are extremely strict with the quality control, in accordance with the standards of European, American and Japanese flat fan nozzle.
For fan nozzles, if you have any questions or doubts, please feel free to consult us. Since the flat fan nozzle itself is a very mature product, we are very familiar with the flow and Angle selection related to its application, and will provide you with the most efficient solution.
